New masterINSTRUCTION MANUALPMR446 FM TRANSCEIVERiF22SRIC-F22SR-(1) 02.3.23 2:29 PM Page 37 (1,1)

52BATTERY PACKSNew master‘‘Battery cautions• CAUTION! NEVER short the terminals of the battery pack (orcharging terminals of the transceiver). Also, c

62BATTERY PACKSNew master‘‘Battery chargingD Regular charging with the BC-146The supplied* BC-146 provides regular charging of optional batterypack wi

72BATTERY PACKSNew masterD Regular charging with the BC-146 (continued)• First insert the spacer in to the BC-146, then insert the battery orthe trans

82BATTERY PACKSNew masterD Rapid charging with the BC-121+AD-94 (#11)The optional BC-121 allows up to 6 battery packs to be charged si-multaneously. T

92BATTERY PACKSNew master‘‘Charging NOTEPrior to using the transceiver for the first time, the battery pack mustbe fully charged for optimum life and o

102BATTERY PACKSNew master‘‘Battery case (Option)When using a BP-208 OPTIONAL BATTERY CASEattached to thetransceiver, install 6 AA (R6) size alkaline

113BASIC OPERATIONNew master‘‘Receiving and transmittingCHARGE the battery pack before first operating the transceiver. The transceiver has been pre-pr

123BASIC OPERATIONNew master• Frequency channel/CTCSS tone list (default)ChannelNo.1No.2No.3No.4No.5No.6No.7No.8No.9No.10No.11No.12No.13No.14No.15No.1

133BASIC OPERATIONNew master‘‘Setting squelch levelThe squelch circuit mutes the received audio signal depending onthe signal strength. q While pushin

143BASIC OPERATIONNew master‘‘Setting the group code numberDDUSING THE CTCSS TONE CODEThe transceiver is equipped with 52 CTCSS tones. (See next page)

New masteriFOREWORDThank you for purchasing the IC-F22SR PMR446 FM trans-ceiver. This PMR FM transceiver meets the European PMR446specification. This t

153BASIC OPERATIONNew masterNo.0123456789101112131415Freq.OFF67.069.3*71.071.974.477.079.782.585.488.591.594.897.4100.0103.5No.16171819202122232425262

163BASIC OPERATIONNew masterDDCTCSS FINDThis transceiver can detect the CTCSS tone frequency in the re-ceived signal. By monitoring a signal that is b

173BASIC OPERATIONNew masterDDUSING THE DTCS CODE This transceiver is equipped with 83 DTCS codes. DTCS operationprovides communication with silent st

183BASIC OPERATIONNew master[Example]To assign code ‘261I (Inverse)’ as CH12;q While pushing and holding [PTT], [S-Ring/C-Ring], [MONI], turn[VOL] to

194RING FUNCTIONNew master‘‘Smart-Ring The ring function has an answer back feature. This allows you toconfirm whether or not a call has reached the m

204RINGER FUNCTIONNew masterDDCall your group member with Call-Ring melody➥ Pushing and holding [S-Ring/C-Ring] to sends a ring tone with-out pushing

215OTHER FUNCTIONSNew master‘‘Monitor audible functionThe monitor function allows you to open the transceiver’s squelchmanually to check whether a cha

225OTHER FUNCTIONSNew master‘‘Power save functionThe power save function reduces the current drain to conserve bat-tery power.• The power save functio

235OTHER FUNCTIONSNew master‘‘Optional HM-75A functionsThe optional HM-75A allows you to remotely send Smart-Ring/Call-Ring calls, open the squelch, e

246SPECIFICATIONSNew masterGENERAL• Frequency coverage : 446.00625–446.09375 MHz• Mode : F3E (FM)• No. of operating Ch. : 8 (simplex)• Power supply re

New masterii 2 types of built-in Code Squelch Systems:CTCSS; Continuous Tone Coded Squelch SystemDTCS; Digital Tone Code Squelch CTCSS* and DTCS* enc

257OPTIONSNew master‘‘OptionsDDBATTERY PACKS• BP-208BATTERY CASEAllows a set of Alkaline batteries to operate the handheld whencharging the rechargeab

267OPTIONSNew masterDDOTHER OPTIONS• HM-46L/HM-75A/HM-131LSPEAKER MICROPHONECombination speaker-microphone that provides convenient oper-ation while h

278GLOSSARYNew master✔ What is squelch?A squelch circuit allows you to mute undesired noise while re-ceiving no signal and emit audio while receiving

288GLOSSARYNew master✔ What is CTCSS (Continuous Tone Coded Squelch Sys-tem) ?CTCSS (Continuous Tone Coded Squelch System) allowscommunication with s

299CENew masterABOUT CECE Versions of the IC-F22SR which display the“CE” symbol on the serial number seal, complywith the essential requirements of th

309CENew masterDECLARATIONOF CONFORMITYWe Icom Inc. Japan1-1-32, Kamiminami, Hirano-kuOsaka 547-0003, JapanKind of equipment: UHF PMR TRANSCEIVERT

INSTRUCTION MANUAL1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 JapanA-6069D -1EU-qPrinted in Japan© 2001 Icom Inc.Count on us!New masterGERAUTGBR

New masteriiiIMPORTANTREAD ALL INSTRUCTIONS carefully and completelybefore using the transceiver.SAVE THIS INSTRUCTION MANUAL–This instructionmanual c

New masterivTABLE OF CONTENTSFOREWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iFEATURES . . . . . . .

New master11PANEL DESCRIPTIONSPMICu External [SP]/[MIC] jackAntennay TX/RX Indicator LEDq [CH] selectorSpeakerMICw [VOL/ POWER]e [S-Ring /C-Ring] key

New master2PANEL DESCRIPTION1q CHANNEL SELECTOR [CH]• Rotate the selector to select the desired channel number 1 to15. (pgs. 11, 12)• Select the Auto

New master31PANEL DESCRIPTION‘‘LED indicatorThe TX/RX indicator LED indicates informa-tion in several ways as follows;(Ref.; R=Red, G=Green, O=Orange)

42BATTERY PACKSNew master‘‘Battery pack replacementBefore replacing the battery pack, the volume control MUST be ro-tated fully counterclockwise,until
